3 Axles U-Shaped Tipper Dump Truck Silinder Hidraulik Belakang Dump Semi Trailer High End Aggregate

Nama merek:	SINOTRUCK
harga:	CN¥158,696.16/units 1-4 units

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Place of Origin:

Shandong, China

Condition:

New And Used

Steering:

Left

Horsepower:

351 - 450hp

Emission Standard:

Euro 2

Segement:

Heavy truck

Market Segement:

Engineering transportation

Fuel Type:

Diesel

Engine Capacity:

> 8L

Cylinders:

Gear Box Brand:

SINOTRUCK

Transmission Type:

Manual

Forward Shift Number:

Reverse Shift Number:

Maximum Torque(Nm):

1500-2000Nm

Dimensions (L x W x H) (mm):

8600x2550x3500

Cargo Tank Dimension:

5600x2300x1500mm

Cargo Tank length:

5.3-6.2M

Gross Vehicle Weight:

10-15T

Capacity (Load):

31 - 40T

Fuel Tank Capacity:

300-400L

Drive Wheel:

6x4

Passengers:

Driver's Seat:

Normal

Rear Camera:

None

Cruise Control:

None

ABS(Antilock Braking System):

Yes

ESC(Electronic Stability Control System):

None

Touch Screen:

None

Multimedia System:

Yes

Window:

Automatic

Air Conditioner:

Manual

Tire Number:

10 or 12

After-sales Service Provided:

Video technical support, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service

Axle:

13/16 Ton Fuwa/BPW/BERKLEY

Function:

Transport Sand

Suspension:

Mechanical Suspension Air Suspension

Tire:

11.00r20 12r22.5 315 385

Rim:

9.00*22.5/6.5-20 (12/16 Pieces) Steel/Aluminum

Color:

Custom's Requirement

Landing Gear:

JOST/FUWA/Yahua Brand 28T

King pin:

2"(50mm)or3.5"(90mm) JOST

Brake System:

WABCO Valve

Capacity:

50T-80T

Menyoroti:

Semi-Trailer Pengeboran Bagian Belakang Silinder Hidraulik

3 poros Semi trailer belakang

U-Shaped Tipper Dump Truck

Deskripsi Produk

Parameter Produk

XIANMANG Rear Dump Tipper Semi Trailer
Aplikasi	Pengangkutan semua jenis Mineral / Batubara / Batu / Pasir / Pengiriman Kargo
Model	2 poros trailer tipper	Truk pengguling 3 poros	4 poros trailer tipper	5 - 6 poros trailer tipper
Kapasitas ember	25 meter kubik	30/35/40 meter kubik	40 meter kubik	45 meter kubik
Dimensi (mm)	850025003500	10000x2500x3800	1050025003900	1150025003950
Velg dan ban	12.00R22.5 ban 9.0-22.5 velg	12.00R22.5 ban 9.0-22.5 velg	315/80R22.5 ban 9.0-22.5 velg	12.00R20 ban 9.0-20
Sistem angkat	Merek HYVA Silinder tipe FE/FC Diameter = 191 mm	Merek HYVA Silinder tipe FE/FC Diameter = 191 mm	Merek HYVA Silinder tipe FE/FC Diameter = 202 mm	Merek HYVA Silinder tipe FE/FC Diameter = 214 mm
Kotak tip	T700 / Hardox
Sinar utama	T700 / Q345B plat ganda
	Tinggi: 500mm
	Piring atas: 14mm
	Piring tengah: 8mm
	Piring bawah: 16mm
Aksel	13T/16T FUWA / BPW / Merek Sendiri
Raja Pin	JOST merek 2.0 '/ 3.5' baut tipe king pin
Perlengkapan pendaratan	JOST 28T kecepatan ganda merek JOST / TAIHUA
Penangguhan	Suspensi mekanik tugas berat / kantong udara / Bogies
Sistem rem pneumatik	Klep relay WABCO RE 6 Kamar rem udara T30/30
Daun musim semi	90 ((W) mm13 ((Kelenjar) mm10 Lapisan atau 100mm12mm12 (khusus untuk pasar ekspor)
Cahaya	Lampu LED, 24V, 7 arah ((7 kabel sabuk)
Kotak alat	Baja/aluminium Satu bagian, 1m0.5m0.5m ((Ukuran dapat dipilih secara bebas)
Lukisan	1 lapis anti korosi primer, 2 lapis cat akhir
Setiap bagian yang dipasang bisa sesuai dengan permintaan klien, hubungi kami untuk mendapatkan lebih banyak
